2" 15,000 PSI Fig 1502 Tapped Male Wing Blind with Nut – Oil & Gas Fitting
2" 15,000 PSI Fig 1502 Tapped Male Wing Blind with Nut – Oil & Gas Fitting
Verfügbarkeit für Abholungen konnte nicht geladen werden
The 2" Figure 1502 Male (Wing) Blind with 1/2" NPT Tap and Wing Nut is a highly versatile, heavy-duty flowline component designed to provide both secure system termination and a direct access point for high-pressure instrumentation. Rated for a Cold Working Pressure (CWP) of 15,000 PSI, this complete tapped bull plug assembly is engineered for the extreme demands of hydraulic fracturing, cementing, and well-testing operations.
Manufactured from premium forged alloy steel, this male blind comes complete with a heavy-duty Figure 1502 wing nut for rapid, secure installation. The precision-machined 1/2" NPT female port integrated into the center of the blind allows operators to easily install pressure gauges, transducers, or bleed-off valves directly at the dead-end of a manifold. This eliminates the need for additional bulky crossover spools, thereby reducing leak paths and saving rig-up time.
Designed for maximum safety and field efficiency, the 2" 1502 Tapped Male Blind assembly ensures a blowout-proof seal utilizing a high-pressure elastomeric lip seal, making it an essential component for monitoring and managing pressure in rigorous upstream environments.
Features & Benefits
-
1/2" NPT Instrumentation Port: Integrated tapped hole allows for the direct mounting of pressure gauges, sensors, or bleed-off valves.
-
15,000 PSI CWP Rating: The Figure 1502 body is engineered for extreme high-pressure service in critical stimulation and testing applications.
-
Complete Assembly: Includes both the tapped male (wing) sub blind and the heavy-duty Figure 1502 wing nut for immediate field deployment.
-
Forged Alloy Steel Construction: Premium materials provide exceptional durability and resistance to impact, vibration, and mechanical fatigue.
-
Positive Elastomeric Sealing: The male sub features a replaceable high-pressure lip seal to ensure a bubble-tight primary seal.
-
Reduced Leak Paths: Consolidates flowline termination and instrumentation access into a single, compact fitting.
Specifications & Technical Details
| Category | Specification |
| Component Type | Tapped Hammer Union Blind (Plug) |
| Figure Number | Figure 1502 |
| Primary Size | 2" |
| Tap Size & Thread | 1/2" NPT Female (National Pipe Thread) |
| Connection Style | Male (Wing End) with Wing Nut |
| Pressure Rating | 15,000 PSI CWP (Body Rating) |
| Material | High-Strength Forged Alloy Steel |
| Seal Type | Elastomeric Lip Seal Ring |
| Typical Applications | Gauge integration, bleed-off points, frac lines, manifolds |
| Testing & Compliance | Hydrostatic testing and material traceability to industry standards |
Applications
This 2" Figure 1502 tapped male blind assembly is ideal for extreme-pressure operations requiring both flowline closure and system access. Typical uses include capping off fracturing or cementing manifolds while providing a port for pressure transducers, acting as a bleed-off point at the end of a well-testing flowline, or facilitating chemical injection into isolated lines.
Quality Assurance
Each tapped blind assembly is manufactured under rigorous quality control standards, undergoing precise dimensional inspection and non-destructive testing (NDT) to ensure the structural integrity of the hammer union connection, the wing nut, and the NPT threaded tap under extreme high-pressure field conditions.
