Blaze Sales & Service

MANUAL GATE VALVE, 3-1/16", 15M, FC-STYLE, EE-0.5 TRIM

MANUAL GATE VALVE, 3-1/16", 15M, FC-STYLE, EE-0.5 TRIM

$6,750.00 USD
$6,750.00 USD
Sale Sold out
Shipping calculated at checkout.

Overview

The Blaze Manual Gate Valve, 3-1/16", 15,000 PSI (15M), FC-Style, is engineered for reliable high-pressure shutoff in the most demanding upstream applications. Manufactured to API 6A requirements and constructed from forged alloy steel, this valve provides consistent isolation performance in wellhead systems, choke and kill manifolds, frac support equipment, drilling manifolds, and high-pressure production operations.

The FC-Style design supports stable gate movement and dependable sealing performance under high-pressure conditions, while the corrosion-resistant trim option is suitable for standard service media such as hydrocarbons, drilling mud, completion fluids, and high-density wellsite fluids. Manual handwheel operation enables controlled actuation where hydraulic or electric systems are not required.

Built for harsh field environments, the Blaze 3-1/16" 15M Manual Gate Valve offers rugged construction, service-friendly access, and reliable performance across continuous pressure cycles.

Features & Benefits

  • API 6A Compliant: Manufactured to recognized wellhead and pressure-control standards.

  • 15,000 PSI Rating (15M): Suitable for extreme high-pressure upstream operations.

  • FC-Style Body: Supports stable gate travel and consistent sealing performance.

  • Corrosion-Resistant Trim: Designed for standard service durability.

  • Reliable Shutoff: Provides dependable isolation in critical applications.

  • Forged Alloy Steel Body: Built to withstand abrasive fluids and high-pressure cycling.

  • Manual Handwheel Operation: Enables direct, controlled actuation without external power.

  • Service-Friendly Design: Facilitates inspection, maintenance, and part replacement.

Specifications & Technical Details

Detailed Specification Table

Category Specification
Valve Type Manual Gate Valve
Size 3-1/16"
Pressure Rating 15,000 PSI (15M)
Design Style FC-Style
Trim Material Corrosion-Resistant Trim (Standard Service)
API Standard API 6A
Body Material Forged Alloy Steel
Operation Method Manual (Handwheel)
Service Type Standard Oilfield Service
End Connections Flanged (other configurations available)
Typical Applications Wellhead, frac, choke & kill, drilling, production
Temperature Rating Based on selected materials
Testing & Compliance Hydrostatic, functional testing, NDT, traceability

Applications

Suitable for extreme high-pressure operations such as:

  • High-pressure wellhead systems

  • Choke & kill manifolds

  • Frac and stimulation equipment

  • Drilling choke and mud manifolds

  • Production flowlines

    • Completion & intervention support systems

Designed for reliable isolation in systems handling abrasive or high-density fluids.

Quality Assurance

Each valve is produced under API 6A and API Q1 quality systems and undergoes hydrostatic pressure testing, functional actuation checks, NDT inspection, and material traceability verification to ensure consistent field reliability.
