Crossover Adapter – 3" FIG 1502 Female (Thread) x 3" FIG 1502 Female (Thread)

The Crossover Adapter, 3" FIG 1502 Female (Thread) x 3" FIG 1502 Female (Thread), is a heavy-duty, forged steel flowline component engineered specifically to join two male (wing) connections within the same large-bore 15,000 PSI high-pressure piping system. This integral adapter provides field operators with a reliable, high-strength solution for connecting standard 3-inch 15K iron pieces without restricting the massive internal flow path or compromising system safety.

A distinct defining feature of this specific adapter is its Female x Female (Thread x Thread) configuration. Both ends feature precision-machined thread (sub) connections, making it an indispensable component for directly mating two male hammer union ends in complex manifold layouts. By bridging these male connections directly, this adapter eliminates the need for inserting unnecessary spacer pup joints or fabricating complex workarounds, which significantly reduces the overall rig-up footprint, minimizes potential leak paths, and ensures a highly streamlined flow rate for large-volume pumping operations.

Features & Benefits

• Female x Female Configuration: Features precision-machined threads on both ends, providing a direct, streamlined solution for mating two male (wing) union connections in tight or complex large-bore rig-ups.

• 15K High-Pressure Capacity: Maintains an uninterrupted 3-inch flow path rated for a full 15,000 PSI cold working pressure, ideal for extreme, high-volume oilfield environments.

• Reduced Leak Paths: Single-piece forged construction replaces hazardous "stacked" configurations, drastically reducing potential failure points and lowering operational risk.

• Heavy-Duty Forged Construction: Manufactured from high-strength alloy steel to withstand severe shock loads, extreme vibration, and massive volumes of abrasive fluid flow.

• Reliable Sealing: Precision-machined seating surfaces ensure compatible elastomeric seals seat perfectly for a bubble-tight, leak-free connection under extreme pressure.

Specifications & Technical Details

Applications

This Female x Female adapter is widely used in high-pressure surface operations where two male 3-inch FIG 1502 union components must be directly joined. Typical applications include massive frac iron rig-ups, high-yield well testing packages, large-bore cementing lines, choke and kill manifolds, pump discharge lines, and general flowback operations requiring secure, large-volume 15K connections.

Quality Assurance

All our adapters are manufactured from premium forged alloy steel and subjected to strict quality control processes. Each fitting undergoes rigorous dimensional inspection and hydrostatic pressure testing prior to shipment to ensure absolute safety, shell integrity, and seal performance under maximum working loads. Full material traceability is available to guarantee compliance with API guidelines.
