Crossover Adapter – 3" FIG 206 Male (Wing) x 3" FIG 206 Female (Thread)

The Crossover Adapter, 3" FIG 206 Male (Wing) x 3" FIG 206 Female (Thread), is a reliable, forged steel flowline component engineered for 2,000 PSI low-pressure fluid transfer systems. This specific adapter functions primarily as a rigid extension, spacer, or gender-changer within a standard 3-inch piping setup. It allows field operators to safely extend a line, bridge a specific gap, or easily adapt a 3-inch FIG 206 male connection to a 3-inch FIG 206 female connection without modifying the primary iron or restricting fluid flow.

In standard surface operations, FIG 206 connections are the industry standard for low-pressure applications, utilizing a secondary O-ring seal to ensure bubble-tight fluid containment even in low-pressure or suction environments. By utilizing this single, integral Male x Female fitting, operators eliminate the need to fabricate temporary, multi-piece threaded workarounds, thereby significantly speeding up the rig-up process and minimizing potential leak paths.

The 3" FIG 206 end features a standard low-pressure male wing configuration complete with a wingnut and the signature FIG 206 O-ring seal for fast, secure installation. The opposing 3" FIG 206 end provides a precision-machined female thread (sub) connection designed to safely seat an identical 206 male profile. The entire assembly is rated for a continuous 2,000 PSI cold working pressure (2K CWP).

Features & Benefits

• Male x Female Configuration: Features a standard 206 wingnut on one end and a precision 206 threaded sub on the other, making it ideal for line extensions or adapting genders in low-pressure setups.

• O-Ring Sealed Profile: The FIG 206 male end incorporates a primary O-ring seal, ensuring reliable, leak-free fluid containment even in suction or low-pressure fluid transfer applications.

• 2K Working Capacity: Maintains an uninterrupted pressure rating of 2,000 PSI, ideal for standard water, mud, and fluid return environments.

• Reduced Leak Paths: Single-piece integral forged construction eliminates the need to stack multiple threaded pipe nipples and fittings, drastically reducing potential failure points.

• Heavy-Duty Forged Construction: Manufactured from high-strength alloy steel to withstand rig environment abuse, vibration, and continuous fluid transfer.

Specifications & Technical Details

Applications

This 3-inch Male x Female crossover adapter is widely used in surface operations requiring reliable, low-pressure fluid transfer. Typical applications include mud tank suction lines, fluid return lines, cement mixing headers, water transfer manifolds, and general low-pressure flowline operations where operators need to extend a line or adapt a 3" 206 connection.

Quality Assurance

All our crossover adapters are manufactured from premium forged alloy steel and subjected to strict quality control processes. Each fitting undergoes rigorous dimensional inspection and hydrostatic pressure testing prior to shipment to ensure absolute safety, shell integrity, and seal performance under working loads. Full material traceability is available to guarantee compliance with API guidelines.
